Grandstream 802.11AC WAVE-2 OUTDOOR LONG RANGE WiFi Access Point (POE/300 Metres)

• 1.77Gbps aggregate wireless throughput
• 2x Gigabit Ethernet ports
• Dual-band 2×2:2 MU- MIMO
• DL/UL OFDMA technology
• Self power adaptation upon auto detection of PoE or PoE+
• Support 256+ concurrent Wi-Fi client devices
• Up to 250-meter coverage range
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data/control lockdown
• 3 Year Warranty
• Flexibility of 2 detachable/changeable antennas for different application scenarios
• Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management

DESCRIPTION

The GWN7660LR is a long-range 802.11ax Wi-Fi 6 access point designed to provide next generation network coverage for indoor and outdoor environments. It offers IP66 weatherproof certified casing, dual-band 2x2:2 MU-MIMO technology and a sophisticated antenna design for extended coverage range of up to 250 meters. The GWN7660LR is supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform that and makes managing your network or several networks across multiple locations easier than ever before. It also uses a controllerless network management architecture in which the controller is embedded within the product’s web user interface for easy administration of locally deployed Wi-Fi APs. The GWN7660LR is the ideal Wi-Fi AP for voice-over-Wi-Fi deployment and offers a seamless connection with Grandstream’s Wi-Fi capable voice and video IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals and dual Gigabit networks ports with PoE/PoE+; the GWN7660LR is an ideal outdoor Wi-Fi access point for enterprises, multiple floor offices, warehouses, parks, hospitals, schools and more.

• 1.77Gbps aggregate wireless throughput
• 2x Gigabit Ethernet ports
• Dual-band 2×2:2 MU- MIMO
• DL/UL OFDMA technology
• Self power adaptation upon auto detection of PoE or PoE+
• Support 500+ concurrent Wi-Fi client devices
• Up to 250-meter coverage range
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data/control lockdown
• Flexibility of 2 detachable/changeable antennas for different application scenarios
• Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management

SPECIFICATIONS

Wi-Fi Standards

IEEE 802.11 a/b/g/n/ac/ax

Antennas

2 dual band external antennas

2.4GHz, gain 3.5dBi

5 GHz, gain 3.5dBi

Wi-Fi Data Rates

5G:

• IEEE 802.11ax: 7.3 Mbps to 1201 Mbps
• IEEE 802.11ac: 6.5 Mbps to 867 Mbps
• IEEE 802.11n: 6.5Mbps to 300Mbps
• IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

2.4G:

• IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps
• IEEE 802.11n: 6.5Mbps to 300Mbps
• IEEE 802.11b: 1, 2, 5.5, 11 Mbps
• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

*Actual throughput may vary depending on many factors including environmental conditions, distance

between devices, radio interference in the operating environment and mix of devices in the network

Frequency Bands

• 2.4GHz radio: 2412 - 2484 MHz
• 5GHz radio: 5180 - 5825 MHz

*Not all frequency bands can be used in all regions.

Channel Bandwidth

• 2.4G: 20 and 40 MHz
• 5G: 20, 40 and 80 MHz

System Security

• WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and
• critical data/control lockdown via digital signatures, unique security certificate and random default
• password per device
• MU-MIMO 2×2:2 2.4GHz, 2×2:2 5GHz
• Coverage Range Up to 250 meters

*Coverage range can vary based on environment

Maximum TX Power

• 5G: 26dBm
• 2.4G: 30dBm

*Maximum power varies by country, frequency band, and MCS rate

Receiver Sensitivity

2.4G

• 802.11b: -99dBm@1Mbps, -90dBm@11Mbps;
• 802.11g: -93dBm @6Mbps, -77dBm@54Mbps;
• 802.11n 20MHz: -74dBm @MCS7; 802.11n 40MHz:-72dBm @MCS7;
• 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -62dBm @MCS11

5G

802.11a: -95dBm @6Mbps, -77dBm @54Mbps;

802.11ac 20MHz: -71dBm@MCS8; 802.11ac: HT40:- 67dBm @MCS9; 802.11ac 80MHz: -64dBm @

MCS9;

802.11ax 20MHz: -63dBm @ MCS11; 802.11ax 40MHz: -62dBm @MCS11;802.11ax 80MHz: -58dBm

@MCS11

SSIDs 32 SSIDs total, 16 per radio (2.4GHz & 5GHz)

• Concurrent Clients 500+
• Network Interfaces 2× autosensing 10/100/1000 Base-T Ethernet Ports
• Auxiliary Ports 1× Reset Pinhole
• Mounting Outdoor wall or pole mount, kits included
• LEDs 1× tri-color LEDs for device tracking and status indication
• Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
• QoS 802.11e/WMM, VLAN, TOS

Network Management

Embedded controller can manage up to 50 local GWN APs

GWN.Cloud offers a free cloud management platform for unlimited GWN APs

GWN Manager offers premise-based software controller for up to 3,000 GWN APs

Power and Green Energy

Efficiency

PoE 802.3af/ 802.3at;

Maximum Power Consumption: 12.9W

Environmental

• Operation:-30°Cto 60°C
• Storage: -30°C to 70°C
• Humidity: 5% to 95% Non-condensing

Physical Unit Dimension:

358.3mm(L)x115mm(W)x45.3mm(H);

Unit Weight: 695g

Entire Package Dimension: 275x185.5x89mm;

Entire Package Weight: 995g

Package Content

GWN7660LR 802.11ax Wireless AP, Mounting Kits, Quick Installation Guide

Weatherproof Grade

IP66-level weatherproof capability when installed vertically

Compliance

 FCC, CE, RCM, IC
