Artistic Space beyond Display, LG Wallpaper OLED Signage
Absolute Black
Equipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.
Rich Color
LG OLED Signage provides richness in all colors, bringing colors to life with great accuracy and vividness.
N×N Expandable Screen Size
By tiling up displays horizontally and vertically, the screen size can be as large as users want. Expansive, large screens are more effective at moving viewers by providing an incredibly immersive viewing experience.
LAN Daisy Chain Management
A LAN daisy chain is supported, allowing you to execute commands to control and monitor the displays and even update their firmware.
Wall Fixers Optimized for Simple Tiling
The overall installation process of the wallpaper OLED has gotten much easier. Once the dedicated wall fixers are driven into a wall, a display can be easily hung on them. Video wall tiling has become more convenient, thanks to its front installation feature, which departs from the conventional sidesliding method.
Enhanced Flexibility of Cables
As a result of in-depth consideration of usage scenarios, improvements have been made to the flexibility of common cables connecting the display to the signage box. These new cables are pliable enough to be easily embedded in a wall or other structures.
Splendid Design
LG’s OLED technology unlocks the new worlds of design flexibility with unbelievably lightweight and slim display. The advantages the OLED display brings are countless from the easier installation to a sleek look.
Hide in Plain Sight
The subtle edge of the wallpaper OLED totally blends in with the wall, giving audiences the sensation that content is being played directly within the wall itself. Integrating with and adding to a luxurious interior design, the wallpaper OLED is an effective method for delivering advertisements and information.
TECHNICAL SPECIFICATIONS
Panel
Screen Size
55”
Panel Technology
OLED
Native Resolution
1,920 X 1,080 (FHD)
Brightness
150 / 400 nit (APL 100% / 25%)
Contrast Ratio
150,000: 1
Color gamut
BT709 120%
Viewing Angle (H x V)
178 × 178
Color Depth
1.07 Billon Colors (10 bit (R)
Response Time
1 ms (G to G), 8 ms (MPRT)
Surface Treatment (Haze)
Hard Coating (2 H), Reflectance Typ. 1.2%
Operation Hours (Hours / Days)
18 / 7 (Moving Content Only)
Portrait / Landscape
Yes / Yes
Mechanical Specification
Bezel Color
Black
Bezel Width
0.9 mm (Even Bezel) (Off Bezel)
5.3 / 5.3 / 5.3 / 11.0 mm (T/R/L/B) (On Bezel)
Weight (Head)
6.5 kg (Head)
3.4 kg (Signage Box)
Monitor Dimensions (W × H × D)
1,220.3 × 696.8 × 4.9 mm (Head)
782.8 × 238.4 × 34.7 mm (Signage Box)
Feature
Key Feature
Internal Memory (16 GB), Sensor (Temperature Sensor), webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected® (Network based control.)), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom
Environment Conditions
Operation Temperature0 to 40
Operation Humidity10%-80%
Power
Power Supply
AC 100-240 V~, 50/60 Hz
Power Type
Built-in Power
Power Consumption
Typ./Max.
116W (IEC 62087) / 318 W
BTU (British Thermal Unit)
1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
Standard (Certification)
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KC
ErP
Yes
Software Compatibility
SuperSign CMS
Yes
SuperSign Control / Control+
Yes
SuperSign WB
Yes
SuperSign Media Editor
Yes
LG ConnectedCare
Yes * The availability can differ by region.
Connectivity
Input
HDMI (HDCP 1.4), DP (HDCP 1.3), RS-232C In, RJ45 (LAN), IR In (External IR Receiver), USB 2.0 Type A (2)
Output
DP Out, Audio Out, RS-232C Out (w / IR Out), RJ45 (LAN)
Language
OSD
English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Arabic
Accessory
Basic
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, FFC Cables (1,600 mm × 4 ea for Connection between Panel and Signage Box), DP Cable (2 M), LAN Cable (1.5 M), RS-232 Cable (4P-4P, 1.5 M), LC Cable (VLC, 3 M), Wall Fixer (4 ea), Wall Fixer Install Guide, Install Guide Sheet (2 ea), Tape (10 ea for Cabling / 2 ea for Dust Proof), Screw (M4 × L25, 10 ea / M3 × L5.5, 8 ea)
