ViewSonic CDE9830 98-in 4K Presentation Display

With stunning 4K Ultra HD resolution, high brightness, and landscape and portrait modes, the CDE30 Series offers continuous and sustainable 24/7 display for both corporate and campus communication. Purpose-engineered for ease of use, the display is equipped with a Quad Core SoC to run multiple operations seamlessly, and its USB-C one-cable solution sorts for effortless connection with external devices. Designed for easy-to-operate continuous multimedia playback, the CDE30 Series offers cable-free screen casting and screen sharing through myViewBoard Display and vCast, which also supports Airplay and Chromecast. Remote management via the intuitive myViewBoard Manager makes changing content, broadcasting, and software updates a breeze. Available in six sizes ranging from 43" to 98", the CDE30 Series features HDMI input and output for seamless tiling of up to 9 screens, meeting the communication needs of any campus, corporate, or retail space.

• Panel Size: 98"
• Type/ Tech: TFT LCD Module. ADS type, DLED backlight
• Display Area (mm): 2158.848 (H) × 1214.352 (V) (98” diagonal)
• Native Resolution: 3840 x 2160
• Aspect Ratio: 16:9
• Colors: 1.07G (8bits + FRC-)
• Brightness: 500 nits (typ.)
• Contrast Ratio: 1200:1 (typ.), 5000:1 (DCR enabled)
• Response Time: 8ms
• Viewing Angles: H = 178, V = 178 typ.
• Backlight Life: 50,000 hours
• Surface Treatment: Anti-Glaire, 3H hardness, Haze 25%
• Bezel: 25/25/25/25 mm (L/R/T/B)
• Orientation: Landscape & Portrait

DESCRIPTION

• With stunning 4K Ultra HD resolution, high brightness, and landscape and portrait modes, the CDE30 Series offers continuous and sustainable 24/7 display for both corporate and campus communication. Purpose-engineered for ease of use, the display is equipped with a Quad Core SoC to run multiple operations seamlessly, and its USB-C one-cable solution sorts for effortless connection with external devices. Designed for easy-to-operate continuous multimedia playback, the CDE30 Series offers cable-free screen casting and screen sharing through myViewBoard Display and vCast, which also supports Airplay and Chromecast. Remote management via the intuitive myViewBoard Manager makes changing content, broadcasting, and software updates a breeze. Available in six sizes ranging from 43" to 98", the CDE30 Series features HDMI input and output for seamless tiling of up to 9 screens, meeting the communication needs of any campus, corporate, or retail space.

Connection Made Efficient

• The CDE30 Series, with its USB-C connectivity, has been designed to enable ease of operation and upgraded efficiency. This all-in-one solution brings together single-cable speedy-data transfers and multimedia broadcasting while powering your connected device and providing it with fast and stable internet access.

Wireless Content Sharing

• The CDE30 Series comes complete with cable-free sharing solutions. myViewBoard Display delivers instant browser-based castings for screen-mirroring with no cable or download necessary, making it perfect for quick presentations and guest users. For more advanced features, vCast offers split, extended, and grouped screen capabilities from any device. It also supports AirPlay and Chromecast so users can effortlessly share their screens.

SPECIFICATIONS

• Panel Size: 98"
• Type/ Tech: TFT LCD Module. ADS type, DLED backlight
• Display Area (mm): 2158.848 (H) × 1214.352 (V) (98” diagonal)
• Native Resolution: 3840 x 2160
• Aspect Ratio: 16:9
• Colors: 1.07G (8bits + FRC-)
• Brightness: 500 nits (typ.)
• Contrast Ratio: 1200:1 (typ.), 5000:1 (DCR enabled)
• Response Time: 8ms
• Viewing Angles: H = 178, V = 178 typ.
• Backlight Life: 50,000 hours
• Surface Treatment: Anti-Glaire, 3H hardness, Haze 25%
• Bezel: 25/25/25/25 mm (L/R/T/B)
• Orientation: Landscape & Portrait

Platform

• Processor: Quad-core ARM Cortex A55
• RAM: 4GB
• Storage: 32GB

INPUT

• HDMI: 2.1x3 ( 3840x2160 @60Hz, HDMI 1 support ARC)
• RS-232: x 1
• OPS Slot: x 1
• WiFi Slot: x 1

OUTPUT

• HDMI: 2.0 x1 ( 3840x2160 @60Hz )
• SPDIF: x 1

LAN

• RJ45: x 1

USB

• Type A: USB 2.0 x 1; USB 3.0 x 1 (USB 3.0 Support Smart USB)
• Type C: x 1 (Support Smart USB, DP1.2, PD 65W, USB2.0, 100M ethernet)

SPEAKERS

• 10W x2

EMBEDDED OS

• Android 11

POWER

• Voltage: 100-240 VAC +/- 10%
• Consumption: 190 W(typ.) < 0.5W(off)

OPERATING CONDITIONS

• Temperature (º C): 0 to 40℃
• Humidity: 10%-90% RH

DIMENSIONS (W x H x D)

• Physical (inch / mm): 87.12 x 49.94 x 3.11in/2212.9 x 1268.4 x 79 mm
• Packaging (inch / mm): 92.91 x 56.1 x 11.02 in./2360 x 1425 x 280 mm

WEIGHT

• Net (lb / kg): 153.0 lbs/69.40 kg
• Gross (lb / kg): 199.1 lbs/90.30 kg

REGULATIONS

• cTUVus, FCC/ICES003, Energy star 8.0, EPEAT, Mexico NOM , Mexico Energy, EMC/CE , CB, EAC, UkrSEPRO, RCM, LBL, Flicker free, Green BOM, RoHS , ErP, REACH, SCIP, WEEE , Annex I, Annex II, TPCH , Packing waste, CA65

PACKAGE CONTENTS

1. Remote Control with batteries
2. Quick Start Guide
3. Power Cables
4. HDMI cable
5. USB-C cable
6. Wall Mount Screw x 4
7. RS232 adapter
8. Compliance statement
