SPECIFICATIONS
Display
Panel Size: 86"
Type/ Tech:
TFT LCD Module. IPS type, DLED backlight
Display Area (mm):
1895.040 (H) × 1065.960 (V) (86" diagonal)
Native Resolution:
3840 x 2160
Aspect Ratio:
16:9
Colors:
1.07G colors
Brightness:
450 nits (typ.)
Contrast Ratio:
1200:1 Typ. , 5000:1 Max.(DCR enable)
Response Time:
8 ms
Viewing Angles:
H = 178, V = 178 typ.
Backlight Life:
30,000 Hours (min)
Surface Treatment:
Anti-glare, 2H hardness, Haze 28%
Bezel:
Slim
Orientation:
Landscape
INPUT
HDMI: x2
RGB / VGA: x1
DisplayPort: x1
Audio: x1 (3.5mm)
RS-232: x1
OPS Slot: x1 (Optional Intel OPS VPC12-WPO)
WiFi Slot: x1 (Optional WiFi module LB-WIFI-001)
OUTPUT
Audio: x1 (3.5mm)
SPDIF: x1 (Fiber)
LAN
RJ45: x1
USB
Type A: 2.0 Type A : x 2 (USB Playback)
3.0 Type A : x 1 (USB Playback)
SPEAKERS
Max. 16Wx2
COMPATIBILITY
RGB PC/HDMI PC: Up to 1920x1080@60Hz. Refer to timing table
HDMI: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz
DisplayPort: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz
Android Version: Android 8.0
POWER
Voltage: 100V-240V,50/60Hz (AC)
Consumption: Normal 178 W, Max 450 W
ERGONOMICS
Wall Mount (VESA® ): 600x400 mm
OPERATING CONDITIONS
Temperature (º C): 0 to 40°C
Humidity: 20% ~ 80% non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 76.02 x 43.67 x 3.24 in/ 1931.0 x 1109.0 x 82 mm
Packaging (inch / mm): 83.39 x 50.05 x 11.02 in/2118 x 1271 x 280 mm
WEIGHT
Net (lb / kg): 50.4 kg / 111.11 lbs (w/o stand)
Gross (lb / kg): 69.8 kg/153.88 lbs
REGULATIONS
cULus, FCC, Energy Star, EPEAT,MX-CoC, Mexico Energy, CE, CB, RoHS, ErP, REACH, WEEE, Custom Union, UkrSEPRO, RCM, MEPS
PACKAGE CONTENTS
1. CDE8620 presentation display
2. Remote control with batteries
3. Quick start guide
4. Power cables (1.5M)
5. HDMI cables x2 (1.5M/3M)
6. Wall mount screw
7. RS232 adapter
